Synthetic Chain Oils

Berusynth range of synthetic chain oils are based on proven synthetics including Esters, Polyalphaolefin (PAO) and Polyglycols. These synthetic chain oils have good ‘Viscosity Index’ characteristics enabling them to operate in a wide operating temperature range (-40°C to +250°C). Berusynth series have minimal evaporation rate even at extreme high temperatures. Polarity within Berusynth Chain oil series ensures good tackiness and creeping properties much required for effective lubrication of chain application. Maintaining a tacky lubricating film, Berusynth series avoid unnecessary spillage from chain ‘I links’ to the component or on the shop floor.

Berusynth Chain oil series is recommended for long term lubrication of heavy duty chains that experience heavy loads, extreme operating temperatures as well as for meeting special requirements such as processing industries. The advanced formulation with special polymer additives offer excellent lubricity for friction partners in boundary and mixed friction zones. The chain oil series by BECHEM leaves minimum residue after active operational life, thereby helping in easier cleaning of chain links.

For more details, send in your query at sales@bechemindia.com or call us at
+91 80 66900800/01/02.

Synthetic Chain Oils

Synthetic high performance, adhesive chain oil with excellent wetting and penetrating properties. Highly adhesive property of the oil ensures minimal drop-off. Berusynth CU 250 provides high resistance against hot and cold water wash-off and also provides outstanding protection against corrosion of friction partners. CU 250 has low evaporation rate even when subjected to high temperatures and leaves no residue after active life. Berusynth CU 250 is NSF H2 certified. Also available in spray form, known as Berusynth CU 250 Spray.

Applications: Recommended for conveyor chains in stenters and drying frames in the textile industry. Also recommended for conveyor chains in paint shops, drying ovens, machines in printing industry , shrink tunnels, lift chains in high-level rack storage facilities. Other applications include conveyor chains in stone wool and glass wool production, dipped latex rubber gloves etc.

ProductBase OilViscosity at [40 °C mm2/s]Flash point °CSend Your Queries
Berusynth CU 250

  • Chains
  • High temperature
  • Corrosion protection
  • High loads
Ester250≥ 250

Synthetic high temperature chain oil for superior lubrication film with high load carrying capacity and provides excellent protection against wear of contacting surfaces. The high performance oil has low evaporation rate even at high temperatures. Berusynth CB 180 H1 has good penetration properties and high wash-out resistance. Berusynth CB 180 H1 is NSF H1 approved as well as Halal and Kosher certified. Resistant to hot and water and provides excellent protection against corrosion.

Applications: Recommended for conveyor chains in baking, drying ovens of food processing and beverage industry. Suitable for chains used in the production of surgery rubber gloves.

ProductBase OilViscosity at [40 °C mm2/s] Flash point °CSend Your Queries
Berusynth CB 180 H1

  • Chains
  • Food grade / Pharmaceutical technology
  • High temperature
  • Corrosion protection
  • High loads
  • Resistant to water
Ester180≥ 240

Applications and Properties

The unique pictograms help identify primary characteristics of the lubricant as well as key applications and industries it has been established at a glance. However the final recommendation would still have to be by the BECHEM specialist after having studied application and its operating environment. As the saying goes, ‘every problem has a unique solution, if only, one is looking for it’. This is the core philosophy to our approach towards ‘Application Engineering’ and staying true to ‘speciality’

Chains

Food grade / Pharmaceutical technology

High temperature

Corrosion protection

High loads

Resistant to water

Frequently Asked Questions

Short bytes for queries on lubricants that always bothered you

Greases are made by mixing a solid material, called a thickener, with a base oil and property enhancing additives; but it’s the oil that forms the lubrication film. For better understanding, grease thickener can be thought of as a sponge saturated with oil. Moving parts squeeze the oil out of the sponge like thickener for forming the lubrication film. Typically, the base oil constitutes the largest proportion of grease weight at about 80-90%, followed by thickener at 10 to 20% and additives under 10%.

Dropping point of a lubricating grease is an indicator of the heat resistance of the grease. and is the temperature at which the grease is no more a thickened lubricating medium. The dropping point indicates the upper temperature limit at which a grease retains its structure, not the maximum temperature at which a grease may be used.

Few greases have the ability to regain their original structure after cooling down from the dropping point.

The most important feature of a grease is its consistency.  A grease that is too stiff may not get pumped into areas requiring lubrication.  While a grease that is too fluid may leak out. Grease consistency depends on the type and amount of thickener used and the viscosity of its base oil.  A grease consistency is its resistance to deformation by an applied force.

The measure of consistency is called penetration.  Penetration depends on whether the consistency has been altered by working.  Standard test procedures established by American Society for Testing and Materials International (ASTM) and accepted by industry are ASTM D 217 and D 1403,  measure penetration of unworked and worked greases.

The NLGI has established consistency numbers ranging from 000 to 6, corresponding to specified ranges of penetration distance of the standard cone into the test grease.  Table below lists the NLGI grease classifications along with a description of the consistency of each classification.

Viscosity: It is a measure of resistance to flow of a lubricating oil.

Viscosity index: It is defined as rate of change of viscosity with respect to temperature.

Significance:

  • It is the most important property which determines the performance of lubricating oils under the influence of temperature
  • A lubricating oil should have sufficient viscosity to retain a lubricating film on the surface
  • On machine part moving at slow speeds under high pressures, a high viscous oil should be used as it better resists being squeezed out from between the rubbing parts.  Light oils can be used for lower pressures and high speeds.
  • It is not possible to maintain a liquid oil film between two moving or sliding surfaces if the viscosity is too low and hence excessive wear will occur.

The pour point of an oil is the minimum temperature at which the oil turns into semi solid and almost losses its flow characteristic. At low temperatures, the viscosity of the oil will be very high, causing the oil to resist flow. This is important in equipment that operates in a cold environment or handles cold fluids.
